Studiomaster C2-2
MIXING AMPLIFIER | STUDIOMASTERThe C2 Series are an ultra compact high quality mixer series, offering comprehensive features normally found on larger consoles in an attractive compact moulded case.
| Channels | 6 |
| Mic Inputs | 2 |
| Stereo Inputs | 4 |
| Frequency Response | 20Hz-20kHz (+/-1dB) |
| Distortion | <0.08% @ -10dBu |
| Residual Noise | <-98dB |
| Mic Gain Range | 0dB to +45dB |
| Line Gain Range | -20dB to +25dB |
| Input Impedance - Line | 20k ohm balanced |
| - Playback+ CDMP3 | 24k ohm unbalanced |
| Crossover frequency | 120Hz |
| EQ Hi | +/-15dB @ 12kHz |
| EQ Lo | +/-15dB @ 80Hz |
| Main Mix Output | Main Mix Output |
| Aux Send Output | Main Mix Output |
| Record out Impedance | 1k ohm |
| Headphone out Impedance | 25k ohm |
| USB | N/A |
| Power Supply | Wall adaptor 100-240V ~ 50/60Hz |
| Dimension (W × H × D) | 244mm x 165mm x 75mm |
